Kacon K16-311-G 16 mm Maintained Push Button, Round, SPDT, Green

Description

The Kacon K16-311-G maintained push button has a round, green lens with an SPDT contact arrangement. Used for 16 mm (5/8″) mounting holes. Snap action contacts are 24K gold plated alloy, rated at 1A & 110VAC. Lens is not illuminated. Rated IP 65 for dust and water protection. With a maintained push button switch, it will remain in the same state, either activated or not, until it is pressed, which will change the state until it is pressed again.

Specifications

• Push Button Type– Maintained
• Lens Shape & Color– Round, Green
• Contact Arrangement– SPDT (1C)
• Contact Material– 24K Gold Plated Alloy
• Overall Dimensions– 39mm L x 18mm Diameter
• Rated Insulation Voltage– 250VAC
• Rated Operating Current-3A Max.
• Max On/Off Current– 250 VAC, 110 VDC
• Rated Load– 1A at 24VDC/120VAC, 0.5A at 250VAC
• Max Applicable Load– 1mA 5VDC
• Contact Resistance– Max. 50 mOhm
• Insulation Resistance– 100 MOhm at 500VDC
• Dielectric Strength-2000 VAC for 1 min
• Vibration Resistance– 25-55Hz dual amplitude: 0.75mm
• Shock Resistance– Endurance: 500m/s², Operating error: 200m/s²
• Mechanical Life (release)– Min. 1,000,000
• Electrical Life– Min. 50,000 (frequency 1200 times/hrs)
• Operating Temperature: -25 C to +55 C (-13 F to 131 F)
• Storage Temperature: -30 C to +80 C (-22 F to 176 F)
• Ambient Humidity-45-85% RH
• Degree of Protection– IP 65
• Terminal Soldering 20W 5sec / 260 C 3sec
• Approvals-UL & CUL Recognized, CE

If you need the push button to perform certain functions, such as having timed on/off cycles, it does require the use of a relay, which is sold separately. Please contact us for more information on Kacon relays

Kacon K16-311-G Maintained Round SPDT Push Button Switch
