ILME CHP-32LS29 C-Type Surface Mount Housing, Size 77.62, Lever & Cover, PG 29

Description

The ILME CHP-32LS29 C-Type surface mount standard housing is size 77.62 and features a single lever with a cover and a PG29 cable entry. The body is epoxy coated die cast aluminum with a polyamide handle and stainless steel lever. Insert center distance: 2 x (77.5 x 27)mm. Rated IP 65 when attached to mating hood. The clamping force supplied by the CHP-32LS29 is constant while the double size can accommodate two corresponding inserts.

Specifications

• Body-Epoxy Coated Die Cast Aluminum
• Gasket-Thermoplastic Elastomer
• Handle-Polyamide
• Lever-Stainless Steel
• ILME Series-CH
• Insert Dimension-77.62
• Enclosure Dimension-77.62
• Housing Type-Standard
• Enclosure Type-1 Lever w/ Cover
• Mounting Style-Surface Mount
• Temperature Range- -40 C to 125 C (-40 F to 257 F)
• Hood Entry-Side
• Hood Thread-PG 29
• Gasket-Yes
• Ingress Protection-IP 65 (Total protection from dust and low pressure water jets from any direction)
• Insert Center Distance-2 x (77.5 x 27) mm 2 x (3.05″ x 1.06″)
• Approvals-C UR US, CCC, GL

Compatible Inserts

CHP-32LS29 77.62 Double Size PG 29 Surface Mount Base
