ILME CDDM-24 CDD Series Insert, Male, Size 44.27, 24 Pin, 10A

Sale!
ILME CDDM-24 CDD Series Insert, Male, Size 44.27, 24 Pin, 10A

ILME CDDM-24 CDD Series Insert, Male, Size 44.27, 24 Pin, 10A

Original price was: $10.69.Current price is: $8.07.

76 in stock

SKU: 9747592770 Category:

Description

The ILME CDDM-24 CDD series standard male insert fits size 44.27 enclosures and is 24 pin + ground with a voltage rating of 600V and a rated current of 10A. The housing is glass reinforced thermoplastic and is self-extinguishing with a rating of UL 94 V0. Rated IP 20. Termination: crimp pin (sold separately). The CDDM-24 is designed for high intensity applications.

Specifications

  • Housing-Glass Reinforced Thermoplastic
  • Gender-Male
  • Pin Count-24 + Ground
  • Rated Current-10 Amps
  • Rated Voltage-600 V
  • ILME Series-CDD
  • Housing Type-Standard
  • Operating Temperature--40 C to 125 C (-40 F to 257 F)
  • Insert Dimension-44.27
  • Enclosure Dimension-44.27
  • Termination-Crimp Pin
  • Upper AWG-14
  • Lower AWG-26
  • Insulation Resistance->= 10GOhm
  • Mechanical Life->= 500 Cycles
  • Contact Resistance-<= 3mOhm
  • Ingress Protection-IP 20 (Protection from objects 12.5mm (0.5″) in diameter or larger)
  • Approvals-UL, CSA, CCC, GL, GOST

Compatible Enclosures

Series Part Number
CH CHI-06L, CHI-06LC, CHI-06LCS, CHI-06LS, CHI-06YC
CH, CA, MH CHP-06L, CHP-06LS, CHP-06L2, CHP-06LS2, CAP-06LSCAP-06L, CAP-06L2, CAP-06L229, CAP-06L29, CAP-06LS2, CAP-06LS29, CAP-06LS229MHP-06L20
CH, CA, MH, MA CHO-06L13, CHO-06L16, CHV-06L13, CHV-06L16, CHV-06LG, CHV-06LX16CAO-06L21, CAO-06L29, CAV-06L21, CAV-06L29, CAV-06LG21, CAV-06LG29MHO-06L20, MHV-06L20, MAV-06L25, MHV-06L25, MAV-06L32, MHO-06L25MAO-06L32, CAV-06YX29, CHO-06LX16, MHO-06LX20
CH CHC-06L, CHC-06LG, CHC-06LC
CH, CA CHIW-06L, CHIW-06LS, CAOW-06L21CAVW-06L21, CAPW-06LS, CAPW-06L29, CAPW-06L229
CH, CA CHIS-06L, CHCS-06L
TC, TM TCHI-06L, TCHC-06L, TMAV-06L32, THIH-06LTMAP-06L25, TMAP-06L32, TMAO-06L25, TMAO-06L32
JCVI JCVI-06L
CG CGI-06, CGO-06.21

Corresponding Crimp Pins

Wire Gauge Part Number
14 CDMA-2.5, CDMD-2.5
16 CDMA-1.5, CDMD-1.5
18 CDMA-1.0, CDMD-1.0
20 CDMA-0.5, CDMD-0.5
22-26 CDMA-0.3, CDMD-0.3

ILME 44.27 24 Pin Male Insert CDDM-24
