Deca A20P-1BEQ4S 22 mm Blue LED Pilot Lamp, Marking Plate Head, 24V

Description

The Deca A20P-1BEQ4S pilot lamp has a blue marking plate style head. Made for 22 mm mounting holes. Lens illuminated by 24V AC/DC LED. Rated IP 65. Pilot lamps, or pilot lights, are utilized to show when an electrical circuit is closed.

Specifications

• Head Type & Color– Marking Plate, Blue
• Housing Dimensions– 26.5 mm Height x 30 mm Width x 33.7 mm Depth (1.04″ x 1.18″ x 1.32″)
• LED Rated Voltage- 24V AC/DC
• LED Rated Current- 0.013 Amps
• LED Lifespan- 50,000 hours
• Insulation Resistance– 100 MOhm at 500VDC
• Dielectric Strength-Contact Block: 2500V AC for 1 Minute, Illuminated Unit: 2000V AC for 1 Minute
• Vibration Resistance– Operation Extremes: 5-55 Hz Amplitude: 0.5 mm, Damage Extremes: 30 Hz Amplitude: 1.5 mm
• Shock Resistance– Operation Extremes: 100m/s², Damage Extremes: 1000m/s²
• Operating Temperature: -25 C to 55 C (-13 F to 131 F)
• Storage Temperature: -45 C to 85 C (-49 F to 185 F)
• Ambient Humidity-45-85% Relative Humidity
• Degree of Protection– IP 65 (Total protection from dust and water jets from any direction)
• Approvals-UL & CUL Listed, CE

Deca A20P-1BEQ4S Blue 24V AC/DC LED Pilot Light
