Boxco BC-CGP-506018 Enclosure, 530x630x185, Solid Gray Hinged Lid, Polycarbonate

Sale!
Boxco BC-CGP-506018 Enclosure, 530x630x185, Solid Gray Hinged Lid, Polycarbonate

Boxco BC-CGP-506018 Enclosure, 530x630x185, Solid Gray Hinged Lid, Polycarbonate

Original price was: $263.75.Current price is: $142.08.

77 in stock

SKU: 4800655908 Category:

Description

Boxco BC-CGP-506018 is a hinged lid enclosure. Back plates used for mounting interior components and optional latch locks sold separately (see below). Gasket is already molded around the lid of the enclosure. Holes can be drilled into the sides for cable glands if cables need to be run through the enclosure.

  • Dimensions (Width x Length x Depth): 20.87″ x 24.8″ x 7.28″ (530 x 630 x 185 mm)
  • Made from polycarbonate
  • Solid gray cover
  • Molded hinges
  • Stainless steel latches
  • Integrated key ring
  • UV resistant
  • -40 C to 110 C (-40 F to 230 F)
  • Rated IP 66/67, NEMA 4X
  • Flammability rating: UL94-V-0, 5VA, 94-HB
  • Impact test: IK07/08
  • UL508, CE, TUV, RoHS
  • Wall mounting brackets included

Boxco P Series Enclosure Downloads

Industrial Enclosure & Junction Box Selector
