Ancor Safety Duplex Cable – 10/2 – 100′ [124110]

Description

Safety Duplex Cable – 10/2 – 100′

Features:

• ANCOR Duplex Cable is made to surpass the highest UL Boat Cable standards with ultra flexible (Type 3/Class K) stranding to resist fatigue due to vibration and flexing.
• Outer jacket is made for easy removal and provides the best abrasion resistance available
• ANCORs proprietary premium vinyl insulation stays flexible even in extreme cold and resists salt water, battery acid, oil, gasoline and ultra-violet radiation. Exclusive insulation is rated at 600 volts, 105°C dry and 75°C wet, and is resistant to heat and abrasion.
• Inner conductors are correctly color-coded to ABYC standards
• Features red and yellow Marine Grade™ primary conductors in white common jacket

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

• Color: Red/Yellow
• Length (Feet): 100′
• Gauge: 10/2 AWG
• Box Dimensions: 5″H x 11″W x 11″L WT: 12 lbs
• UPC: 091887805864

Quick Guide (pdf)
Brochure (pdf)
