AGFRC SA81FHMW Metal-Gear Waterproof-Servo-Motor High-Torque – 74KG

Sale!
AGFRC SA81FHMW Metal-Gear Waterproof-Servo-Motor High-Torque - 74KG

AGFRC SA81FHMW Metal-Gear Waterproof-Servo-Motor High-Torque – 74KG

Original price was: $119.96.Current price is: $75.89.

18 in stock

SKU: SA81FHMW Category:

Description

Feature

Full CNC Aluminium Shell

Smoothly 4 Ball Bearings

Super Strong 4-Pole Brushless Motor

High Strength Steel Gears

Magnetic Angle Sensor Waterproof IP67

Programmable Smart Function for Regular and Winch

Ideal for On-Road, Off-Road and Truck cars, Plane, Robot and Engine etc.

Specification

SA81FHMW

Operating Voltage: 4.8-8.4V

Operating speed: 0.190sec/60° @ 4.8V

Operating speed: 0.165sec/60° @ 6.0V

Operating speed: 0.135sec/60° @ 7.4V

Operating speed: 0.125sec/60° @ 8.4V

Stall Torque: 45 kg-cm (625 oz-in) @ 4.8V

Stall Torque: 55 kg-cm (764 oz-in) @ 6.0V

Stall Torque: 65 kg-cm (903 oz-in) @ 7.4V

Stall Torque: 74 kg-cm (1028 oz-in) @ 8.4V

Gear: Steel

Motor: BLS

Size: 40*20*38mm (1.57 x 0.78 x 1.49 in)

Weight: 85g

Connector Wire: TYU 300mm / 22AWG
